Digital Level Hand Tool
TECHNICAL DATA QUICK REFERENCE* MODEL
80 100 200 280Pro 600 680Pro 1000XY
      NEW
Type Pocket-Size Module Torpedo Waterproof Heavy Duty Waterproof 2-Axis Post
Measuring Range (Single Axis) 0° ~ ±90° 0° ~ ±90° 0° ~ ±90° 0° ~ ±90° 0° ~ ±90° 0° ~ ±90° 0° ~ ±90°
Measuring Range (Dual Axis)             0° ~ ±45°
Resolution : 0.1° (1.745mm/M) DWL80E,80G DWL100 DWL200
0.05° (0.873mm/M) DWL80Pro DWL130,180 • DWL600 • •
Accuracy : 0.1° DWL80E,80G DWL100 DWL200
0.05° DWL80Pro DWL130,180 • DWL600 • DWL1000XY
(°) Degree, % slope • • • • • •
inch/ft，mm/M   • • • • •
Buzzer Sound   • • • • • •
HOLD function to freeze reading   • • • • • •
Built in Vials •   • • • • •
Magnet •   • • • • •
Backlight LCD Display       LED • OLED Display Color TFT Display
Alternate Zero (Set any angle to 0) • • • • • • •
Inverted Reading DWL80Pro • • • •
Auto shut off (Power saving) • • • • • • •
User self calibration • • • • • • •
Dimension**(L)×(H)×(W)mm 107 x 55 x 18 95 x 54 x 43 (DWl-130)
118 x 49 x 16 (DWL-180)		 200 x 43 x 18 230 x 57 x 28 600 x 60 x 30 600 x 60 x 30 61 x 121 x 52
Approx.Weight(g) 100 100/110 140 350 750 800 496
Operating Temp. 0°~+50°(Celcius) • • • -20°~+60° • -20°~+60° •
Storage Temp. -10°~+60°(Celcius) • • • -30°~+70° • -30°~+70° •
Waterproof Rating       IP67   IP65
Batteries 2 x CR2032 2 x CR2032 2 x CR2032 3 x AAA 2 x AAA 4 x AAA 2 x AAA

* Product Specification and appearance are subject to change for product improvement without prior notice.

** Dimension stated in this chart is approximation.


Notes:

Blank Space - indicate this feature is not available for this model

Dot "•" indicate that all models from this series have this feature.
2-Axis Precision Levelling Instrument
TECHNICAL DATA QUICK REFERENCE* MODEL
DWL2000XY DWL3000XY DWL3500XY DWL8500XY
      New
Measuring Range (Single Axis) 0.00° ~ ±90.00° 0.00° ~ ±90.00° 0.000° ~ ±20.000° 0.0 to 14400 arcsec. (0.0000° to ± 4.0000°)
Measuring Range (Dual Axis) 0.00° ~ ±3.00° 0.00° ~ ±15.00° 0.000° ~ ±10.000° 0.0 to 7200 arcsec. (0.0000° to ± 2.0000° )
Resolution : 0.01° (175μm/M) (0.002 in/Ft) 0.01° (175μm/M) (0.002 in/Ft) 0.001° (18μm/M) (0.0002 in/Ft) 1 arcsec. (≤ 5µm/M)
Accuracy : ± 0.02° at 0.00° ~ ± 2.00°
(349 μm/m)
(0.004 in/Ft) (72 arcsec.)
± 0.04° at other angles		 ± 0.01° at 0.00° ~ ± 10.00°
(175μm/M)
(0.002 in/Ft) (36 arcsec.)
± 0.03° at other angles		 ± 0.001° at 0.000° ~ ± 2.000°
(18μm/M)
(0.0002 in/Ft) (3.6 arcsec.)
± 0.003° at other angles		 ± 1 arcsec. at 0 ~ 1080 arcsec.;
3 arcsec. at other angles
Repeatability 0.01° (175μm/M) (0.002 in/Ft) 0.01° (175μm/M) (0.002 in/Ft) 0.001° (18μm/M) (0.0002 in/Ft) 1 arcsec. (≤ 5µm/M)
Measurement Speed ≤ 3 Sec. ≤ 3 Sec. ≤ 5 Sec. ≤ 5 Sec.
Vibrometer (Relative g) 1.0 2.0 2.0
Magnet •
Display Colour TFT LCD
Power Supply** 4 x AAA 1.5V Batteries / USB
Material PC ABS / Aluminium PC ABS / Cast Iron PC ABS / Cast Iron / Titanium
Connectivity USB 2.0 Cable (≤ 5 Meter) USB 2.0 Cable (≤ 5 Meter)
Bluetooth Industrial Class 1 (≤30 metre) (Optional)		 USB 2.0 Cable (≤ 5 Meter)
Bluetooth Industrial Class 1 (≤30 metre)
Operating Temperature -10°C to +50°C (Calibrated for the entire temperature range) +10°C to +40°C (Calibrated for the entire temperature range)
Storage Temperature -20°C to +60°C
Dimension (mm) 188 x 62 x 37
Nett Weight (Approximate) 580 gram 1100 gram 1150 gram
User Self Calibration Yes

* Product Specification and appearance are subject to change for product improvement without prior notice.

** Alternative device power can be obtained from External USB Power Source


Notes:

Blank Space - indicate this feature is not available for this model

Dot "•" indicate that all models from this series have this feature.
2-Axis Inclination Sensor Module
TECHNICAL DATA QUICK REFERENCE* MODEL : Industrial-Grade
DWL5000XY DWL5500XY

Measuring Range (Single Axis) 0° ~ ±90.00° 0° ~ ±10.000°
Measuring Range (Dual Axis) 0° ~ ±15.00° 0° ~ ±5.000°
Resolution : 0.01° (175μm/M) (0.002 in/Ft) 0.001° (18μm/M) (0.0002 in/Ft)
Accuracy : ± 0.01° at 0° ~ 2.00°
± 0.03° at other angles		 ± 0.001° at 0° ~ 2.000°
± 0.003° at other angles
Repeatability 0.01° (175μm/M) (0.002 in/Ft) 0.001° (18μm/M) (0.0002 in/Ft)
Cross Axis Error (Dual Axis Mode) Negligible (± 0.0025°) Negligible (± 0.00025°)
Vibrometer (Relative g) 1.0 2.0
Response Time 10ms (Milliseconds) 500ms (Milliseconds)
Power Supply 9V DC
Output Mode RS232/ RS485: 8 Data bits, no parity, 1 stop bits, 115200bps
USB 2.0 or Wireless Bluetooth connectivity (optional)
Sensor Module Waterproof Rating IP65
Sensor Module Base Material Aluminium Base - Cast Iron / Top cover-Aluminium
Sensor Module Dimension (mm) 90 x 60 x 33
Sensor Module Weight (approx.) 400g 600g
Operating Temperature 4°F to 158°F or -20°C to +70°C
Storage Temperature -30°C to +80°C

* Product Specification and appearance are subject to change for product improvement without prior notice.


Notes:

Blank Space - indicate this feature is not available for this model

Dot "•" indicate that all models from this series have this feature.

Digi-Pas® PC Sync Software & Mobile Apps
Feature PC Sync Software Mobile Sync Apps
Pc Sync Basic Pc Sync Pro Mobile Sync Basic Mobile Sync Pro
DWL3000XY DWL3500XY DWL2000XY DWL3000XY DWL3500XY DWL3000XY DWL3500XY DWL3000XY DWL3500XY
Single-Axis Angle Meter • • • • • • • • •
Dual-Axis Angle Meter • • • • •     • •
Smart 2D Bubble®     • • •     • •
Single-Axis Angle Graph • • • • •
Dual-Axis Angle Graph       • •
VibroMeter Graph       • •
USB Connectivity • • • • •
Bluetooth Connectivity       • • • • • •

Notes:

Blank Space - indicate this feature is not available for this model

Dot "•" indicate that all models from this series have this feature.
